2x · prime

Hawk C-Series Anamorphics

The Hawk C-Series delivers thoroughly modern, sharp imagery that is also slightly forgiving with a very natural feel. Designed with an understanding of how filmmakers work, the C-Series includes a 60mm prime a very practical focal length alongside a 55-165mm front anamorphic zoom. A focused, practical set covering the most commonly used focal lengths for Super 35 production, with proven anamorphic character across both primes and zoom.

Compact Design
2x Anamorphic Squeeze
Oval Bokeh
Anamorphic Flare
Arma Cine Compatible

Focal Lengths

T-Stop

T2.2

Squeeze

Front Ø

110mm

Enquire About Rental Open a Rental Account →

Technical Data

HAWK C-SERIES ANAMORPHICS

Lens	Focal Length / Stop	CFD	MOD	AoV H°	Weight	Front Ø	Overall Length	Min. Filter	Image Diagonal	Illum. Diagonal
Hawk C-Series 40	40mm / T2.2	2'11"	2'5"	67.5°	4.7 lbs	110mm	143mm	4×5.65"	29mm	30mm
Hawk C-Series 50	50mm / T2.2	3'	2'6"	56.2°	4.7 lbs	110mm	162mm	4×5.65"	30mm	31mm
Hawk C-Series 60	60mm / T2.2	3'	2'6"	46°	4.7 lbs	110mm	173mm	4×5.65"	34mm	35mm
Hawk C-Series 75	75mm / T2.2	3'1"	2'5"	37°	5.4 lbs	110mm	187mm	4×5.65"	35mm	38mm
Hawk C-Series 100	100mm / T3	3'3"	2'6"	27.5°	6.2 lbs	110mm	218mm	4×5.65"	40mm	42mm
Hawk C-Series 100 MKII	100mm / T2.8	3'	2'5"	27.5°	5.1 lbs	110mm	185mm	4×5.65"	40mm	42mm
Hawk C-Series 55-165	55-165mm / T4	2'11"	2'4"	48°–15.6°	5.4 lbs	110mm	194mm	4×5.65"	31.5mm	32.5mm

1. Angle of view – quoted for S35 format (22.94 × 19.22 mm – 2.39:1 Release Format – Sensor size ALEXA 35) 2. C-Series with Arma Cine: Orbital system for clip-on matte boxes, designed for lenses with rotating and extending front elements. Increases front diameter from 110 mm to 125 mm and adds ~300 g/0.7 lbs.
